| Merk – Marque: | Molto Luce |
| Materiaal – Materiaux: | Extruded Aluminium |
| Type: | Light Insert |
| Afmetingen armatuur – Dimensions armature: | L = 950 mm / L = 1400 mm / L = 2100 mm |
| Kleur – Couleur: | Zwart-Noir / Wit-Blanc / Aluminium Anodized |
| Diffuser – Diffuseur: | 15º / 45º / 34º + 15º |
| Uitrusting – Equipement: | LED |
| Systeemvermogen – Puissance de système: | 20W / 37W / 55W |
| Kelvin graden – Degré Kelvin: | 3000°K / 4000°K |
| Lumen: | 20W
15º & 45º: 1530 lm (3000ºK) / 1650 lm (4000ºK) 15º + 45º: 1450 lm (3000ºK) / 1560 lm (4000ºK)
37W 15º & 45º: 3060 lm (3000ºK) / 3300 lm (4000ºK) 15º + 45ºº: 2900 lm (3000ºK) / 3130 lm (4000ºK)
55W 15º & 45º: 4590 lm (3000ºK) / 4960 lm (4000ºK) 15º + 45º: 4350 lm (3000ºK) / 4700 lm (4000ºK) |
| RA – CRI: | >90 |
| UGR: | <19 |
| Afkoeling – Refroidissement: | Passief – Passif |
| Voorschakelapp – Ballast: | LED driver |
| Voeding – Alimentation: | 220-240V AC |
| Bescherming – Protection: | IP20 |
| Norm – Norme: | CE EN60598-1 |
| CIE fluxcode: | Op aanvraag – Sur demande |
| Optie – Option | Push / DALI ( Only for 7-pole & 7+4 pole versions) |
One Row Lens Light Insert
Technische Fiche
Technische tekening
