| Merk – Marque: | Climar |
| Type: | Opbouw / Apparent |
| Afmetingen armatuur – Dimensions armature: | Ø38xCmm
C = 994mm / C = 1500mm C = 2000mm |
| Diffuser – Diffuseur: | Opal PMMA |
| Bundel – Faisceau: | 300º |
| Uitrusting – Equipement: | LED |
| Systeemvermogen – Puissance de système: | 12W /18W / 24W |
| Kelvin graden – Degré Kelvin: | 3000°K / 4200°K |
| Lumen: | 12W:
1153lm (3000 °K ) / 1203lm (4000°K) 18W: 1730lm (3000 °K ) / 1805lm (4000°K) 24W: 2307lm (3000 °K ) / 2405lm (4000°K) |
| RA – CRI: | >80 |
| Afkoeling – Refroidissement: | Passief – Passif |
| Voorschakelapp – Ballast: | External LED driver |
| Voeding – Alimentation: | 230V / 50Hz |
| Bescherming – Protection: | IP40 / IK04 |
| Norm – Norme: | CE EN60598-1 |
| CIE fluxcode: | Op aanvraag – Sur demande |
| Optie – Option | DALI / Push / DSI / DIM 1-10V / Phase-cut
Turnable White / RGB / RGBW
Emergency: 1 Hour / 3 Hours / DALI 1 Hour / 3 Hours
Sensor: Motion sensor / Ambient Light / Motion & Ambient Light
CRI>90
Bluetooth Control System
2700ºK / 5000ºK / 6500ºK |
Tupoli 38 Surface
Fiche technique
Dessin technique
